Why it is HTG-680 4E

HOME » HIGH-TECH-GRINDING » Grinding machine

HTG-680 4E

Remote control grinder


The HTG-680-4E is a remote controlled, powerful floor grinder with compact design to pass through a standard door. The remote control sets the operator free to manage hoses and cables while still grinding, for up to 40% higher productivity. The drive battery simplifies transportation. This is one of the best ideal machine for most grinding jobs, industrial, commercial or residential. The intuitive HMI Screen on the panel gives you continuous feedback and control over the grinding process. The planetary 4-head system delivers extreme productivity. Suitable for all applications: floor prep, grinding and polishing.

GRINDER FEATURES

●  HMI system,

●  Flexible turning system,

●  Oscillating Grinding( OSdriving™ ) system,

●  Mist spray water System,

●  Effortless transportation system,

●  Swing weights system,

●  Multi-functional plates system,

●  Patent gearbox with MAGcleaning™ system

●  Make U-turn by one button

● Autopilot system

● floating dust cover system


Change your workflow with a touch of a button! High tech grinding HTG-680-4E with remote control offers easy grinding and polishing, and effortless transportation and loading. It can also be used in manual modes.


Product:

HTG-680-4E

Working width:

 680mm

Motor Power:

 11KW / 15HP

 220V / 380V 3phase

Working speed:

 350-1680rpm

 Φ230mm x 4heads

Operation:

 Remote control system

 Water tank

 16L

Weight:

 515kg

Packing size:

150*87*132cm

Acceptable tools:

 Standard HTG tools plate

 Customized is available

Package with:

 Maintenance bag
